SATA III 6Gb/s SSD220S
Transcend's SATA III 6Gb/s SSD220S uses the latest 3D NAND technology that features vertical, stacked expansion of storage cells. By using high-quality flash memory and enhanced firmware algorithms, the SSD220S delivers greater performance and reliability.
3D expansion to break through limits
Unlike planar NAND memory, 3D NAND flash features memory cells stacked vertically in multiple layers. 3D NAND overcomes density limitations of 2D planar NAND, and delivers a higher level of performance and endurance.
Performance boost for everyday computing
Taking full advantage of the SATA III 6Gb/s interface and built-in SLC caching technology, Transcend's SSD220S achieves exceptional transfer speeds of up to 530MB/s read and 480MB/s write.
Guaranteed endurance and reliability
Transcend's SSD220S offers great Terabytes Written (TBW) values (up to 160 TB) indicating the total amount of data you can write into the drive over its lifetime.
A better choice than HDD
Solid-state drives dominate the market for PC upgrades because they are faster and lighter than hard disk drives. SSDs also feature less power, create less noise when in operation, and are more shock-resistant than traditional hard drives.
3 easy steps to upgrade your PC
Transcend's SSD220S measures just 6.8mm in height and features short access times, making it a perfect choice for upgrading desktops, laptops, and the latest gaming consoles in just 3 easy steps!
TECHNICAL SPECIFICATIONS
APPEARANCE | |
Dimensions | 100 x 69.85 x 6.8 mm (3.94 x 2.75 x 0.28") |
Weight | 45 g |
STORAGE | |
Flash Type | 3D NAND flash |
Capacity | 240 GB |
OPERATING ENVIRONMENT | |
Operating Temperature | 0°C (32°F) ~ 70°C (158°F) |
Operating Voltage | 5V±10% |
PERFORMANCE | |
Sequential Read/Write (CrystalDiskMark) | 500/330 MB/s |
4K Random Read/Write (IOmeter) | 40,000/75,000 IOPS |
Terabytes Written (TBW) | 80 TBW |
Mean Time Between Failures (MTBF) | 1,000,000 hour(s) |
Drive Writes Per Day (DWPD) | 0.3 (3 yrs) |
Note |
|
WARRANTY | |
Certificate | CE/FCC/BSMI |
Warranty | Three-year Limited Warranty |
PACKAGE | |
Contents | Full unit |
SYSTEM REQUIREMENTS | |
Operating System |
|
TECHNOLOGY | |
TRIM & NCQ Command | Yes |
S.M.A.R.T. | Yes |
DDR3 DRAM Cache | - |
Advanced Garbage Collection | Yes |
DevSleep Mode | Yes |
RAID Engine | Yes |
LDPC Coding | Yes |
.
