High Speed Cables deliver high-definition performance.
HDMI has become the standard digital connection, delivering the highest-quality audio and video signal over a single cable. Manhattan High Speed HDMI Cables are designed and carefully constructed to meet the evolving needs of the high-definition marketplace. Manhattan High Speed HDMI Cables provide 1080p resolution, an audio return channel and a bandwidth of 10.2 Gbps at 340 MHz. These high-quality cables provide high-definition video and multichannel, digital audio with increased performance characteristics, greater accuracy and expanded features, including Internet connectivity for home entertainment devices using a single HDMI connection.
Features:
Supports HDMI Ethernet Channel, Audio Return Channel, 3D Video, 1080p Display and Deep Color
High-speed Ethernet, bi-directional networking at up to 100 Mbps
ARC allows HDMI TV to communicate with home audio systems; no need for additional audio cable
Up to 1080p resolution in 3D and Deep Color
Compatible with any HDMI device, such as Blu-ray, game consoles, stereos and PCs
Compliant with High Speed HDMI specifications
Up to 10.2 Gbps at 340 MHz bandwidth
Double shielded to reduce EMI and other interference sources
Molded PVC boot
Lifetime Warranty
Standards and Certifications
UL 20276
ISO 9002
General
Bandwidth: 10.2 Gbps
340 MHz
HEC support
Meets or exceeds existing HDMI standards
Length: 7.5 m (25 ft.)
Contacts
2 HDMI 19-pin male
Nickel-plated contacts
Molded PVC boot
Double shielded
30-AWG cable
Electrical
Current rating: 0.5 A DC
Withstanding voltage: 300 VDC
Insulation resistance: 50 M?
Conductive resistance: 2 ?
Thermal plastic casing
Package Contents
High Speed HDMI Cable with Ethernet Channel
